IT168 evaluation According to Sino mobile phone sales data for the first half of 2016, OPPO mobile phone ranked second in the Chinese market with more than 29 million units. Among them, the OPPO R9 series with a sales volume of over 7 million in sales for 88 days is undoubtedly the core driving force behind the OPPO mobile phone's sudden emergence this year. Therefore, as an iterative product, the debut of the OPPO R9s is not only enveloping but it is also accompanied by immense pressure - and first of all, it will not continue to exceed the achievements of its predecessors, at least to continue this glory. Therefore, OPPO R9s again picked up OPPO's weapon - camera phone.
OPPO R9s Review: rewrite camera phone ranking new
Since the launch of the VOOC Flash Charge in 2014, "Recharging 5 minutes and talking for two hours" is the secret weapon of the OPPO mobile phone. However, the slogan "I am full of electricity, this time we talk and take pictures," sneaked out and brought out the OPPO R9s. OPPO is so confident, in addition to VOCA flash charge technology in recent years, "how lonely is invincible", the OPPO R9s this 16 million-megapixel camera, support F1.7 aperture and the first Sony IMX398 sensor, can indeed make people full of superiority.
OPPO R9s detailed parameters
Mobile phone model OPPO R9s screen size 5.5 inches, using the fifth generation Corning Gorilla glass resolution 1920 × 1080 processor Qualcomm MSM8953 (Dragon Long 625) frequency 64-bit quad-core 2.0GHz body storage 64GB support extended 128GB operating memory 4GB main camera 16 million pixels (Sony IMX398 ) / F1.7 aperture front camera 16 million pixels / F2.0 aperture body size 153x74.3x6.58mm body weight 145g battery 3010mAh body color gold / rose gold / black operating system ColorOS 3.0 (Based on Android 6.0 ) network standard full Netcom 4G + dual card dual standby price 2799 yuanAppearance: once again leading the industry
From the first impression of getting started, from the screen size to the body measurements, and even the width of the frame, OPPO R9s and R9 did not change much. OPPO R9s still exudes the kind of fresh temperament that is suitable for the tastes of young users, but after I turned over the back of the fuselage, I learned that OPPO R9s is not simply a continuation of OPPO R9.
Open the package, um, or that taste
The first time I saw the back of the OPPO R9s, I could not help wondering where this signal overflows the antenna. I saw the upper and lower parts of the metal shell, respectively, there are three horizontal lines, feel like a separate staff. As we all know, the signal overflow antenna is a necessary part of the metal case phone, otherwise the phone will not be able to talk and go online.
Touch screen mobile phones are on the back
The answer is OPPO R9s creatively common antenna overflow signal into three, since each antenna channel width of only 0.3 mm, that is deliberately not look carefully carved out of the cut surface of the decorative metallic ARTS by CNC - OPPO this known For the "micro slit antenna " , the general signal overflow antenna width is about 1.5 mm, horizontally quite ugly on the fuselage. However, because there is no antenna to maintain normal signals, the industry has been distressing how to hide this “white belt †-like thing. Before the OPPO R9s, it was a very pleasing design to move the antenna to the frame like Apple or Meizu. The arrival of the OPPO R9s has undoubtedly brought about a creative approach to signal overflow antennas .
The signal divided into three overflows the antenna
Move to iPhone 7 (left) on the border, OPPO R9s divided into three, do not know which one you prefer
Speaking of this author also turned over the old account, preemptive iPhone 3 released three-piece design OPPO Finder (left)
　　 The OPPO R9s's built-in battery capacity increased by 169mAh from the R9 to 3010mAh, but the thickness was 0.02mm thinner than the latter, while the OPPO R9s maintained a good level of R9 of only 145g in weight.
OPPO R9s
In addition to the thin and light body, only the 74.3 mm fuselage width further improved OPPO R9s grip, although this is a 5.5-inch quasi-large screen mobile phone. For reference, the 5.5-inch iPhone 7 Plus has a 77.9-mm body and a weight of 188 grams. In front of the iPhone 7 Plus, the OPPO R9s appear lighter and smaller.
OPPO R9s
The measured thickness is even thinner than the nominal thickness
In addition, the OPPO R9s appear to be thinner than the actual touch. Why is this? The answer lies on the border of the OPPO R9s. From the figure below, it can be seen that the frame of the OPPO R9s is different from the general arc-shaped frame, and the border of the OPPO R9s is added to an arcuate transition. While not affecting the touch, there is also contrast between light and shade on the border. Because the eye is very sensitive to light changes, the vision will not consciously fall on the top, no wonder OPPO officials called this design a "concave " waistline.
It's a little regrettable that the volume button is a little bit virtual, and we are looking forward to the production machine can pay attention to the details here.
OPPO R9s continue to be equipped with a 16 million pixel front camera, careful small partners should be noted. The position of the R9s and R9 front camera and sensor groups is exactly the reverse. Do not know if the boss of OPPO forced the designer to have to be a bit different, and the result was that the designer reversed the position.
OPPO R9s beauty effect is quite good, behind will explain it to everyone
Touch the Home button to unlock, without first lighting the screen. The menu key and return key are still retained, but the former function becomes shortcut to open the task manager. It is also convenient to use. It is the brightness of these two buttons is relatively small, anyway, can be seen with the naked eye, but in a bright environment can not take pictures.
Touch the Home button, before the habit of the physical Home key slightly adapt to the next
OPPO R9s fingerprint unlocking speed experience
Photographing: Make mobile photography more interesting
As an iconic product of OPPO's return camera phone, the photo experience of OPPO R9s is naturally the focus of this evaluation. The OPPO R9s starts with a 16-megapixel camera built on the Sony IMX398 and supports F1.7 aperture. In this price segment of the mobile phone, OPPO R9s main camera hardware parameters can be called luxury packages.
OPPO R9s makes photography more interesting
However, the increase in parameters has brought about what kind of change? Just as I had an OPPO R9 Plus on my hand, a 16-megapixel camera based on the Sony IMX298 was used to support F2.0 aperture, and the same structure as the R9s was 6P. From the comparison of the real phones of the two mobile phones, the OPPO R9s has a larger camera. According to the formula lens focal length ÷ lens pass diameter = maximum aperture, because OPPO R9s focal length of 4.1 mm, R9 Plus is 3.79 mm, converted to the former through the light diameter of 2.45 mm, which is 1.89 mm, the greater the diameter of the light into the amount of light more.
OPPO R9s camera caliber is much better than R9 Plus
Softer focus
The familiar partner who knows to take pictures knows that the larger the aperture is, the shallower the depth of field is, resulting in a more ambiguous out-of-focus imaging, which is what we usually say. Blinding is a commonly used technique for photographing. It not only highlights the subjects that are photographed, but also creates contrast, three-dimensionality, and so on. Although the aperture of a mobile phone cannot be compared with a professional single-phase inverse, the physical laws are still the same.
　　 Its real-time photos under a lot of mobile phones are not bad, as long as the user knows a little bit of perspective and tips can shoot good photos. OPPO R9 Plus, which supports 2.0 aperture, has a nice blur effect, but the F1.7 aperture OPPO R9s is even better than this. At the same distance, the R9s can already feel very soft focus.
OPPO R9s has been pasted out of focus
The closest focusing distance of the OPPO R9s is 8 cm, and the distance in the test is about 14 cm. This means that if you use the macro technique, we can also get photos with better blur effect.
Location of mobile phone, theme and background
Low-light imaging is more clear
In addition to better blur, large apertures can also bring in more light. In addition, due to Sony IMX398 light into the 100% increase, but also further enhance the performance of OPPO R9s under low light. The author turned off all the lights in the office and hid in a dimly lit meeting room to take a picture of a coffee machine. It can be seen that the pictures taken by the OPPO R9s are brighter, and they also compensate for the color temperature.
Low-light environment proofs contrast
100% of the screenshots will see a more obvious difference, because the relative amount of light into the larger, OPPO R9s imaging did not appear obvious early, color, color temperature, detail, sharpness are retained. The OPPO R9 Plus is not full of screen noise, but the lack of light has caused the photo blur and color cast.
The difference between the details under low light is more obvious
Focus faster
In the era of contrast focus, the focus speed of the mobile phone is very slow. Until the PDAF phase focus became available, the focus speed of the mobile phone was significantly improved. This time with the Sony IMX398 OPPO R9s, it brings us dual-core focus. Prior to this, only the flagship Samsung S7 series and LG G5 support dual-core focusing technology. About the technical white paper We do not have much to say here, or directly look at the difference between dual-core focus and PDAF focus.
　　 Detailed explanation about dual-core focusing, you can poke here
OPPO R9s (left) is slightly faster than R9 Plus (right) in daylight
In the low-light environment, OPPO R9s supporting dual-core focusing is quite obvious
Really making proofs
PS: Individual proofs were compressed or cropped due to upload size limitations
Say so many theories still have to shoot a few experiences, OPPO R9s in the camera interface and there is not much change, the operation is still easy to learn mainly. However, the old version of the lower right corner of the more camera options button moved to the upper right corner, replaced by a rotating lens button. Taking into account the OPPO R9s equipped with 16 million pixels front camera, user self-timer is also a consideration.
R9s (left one), R9 Plus (right one)
First of all, a few outdoor, the weather is good recently, blue sky and white clouds are suitable for outdoor photos. However, such a large light ratio can easily lead to distortion of the screen. For example, the sky is obviously blue, but the photographs taken on the computer always have a gray feeling. Fortunately, the OPPO R9s did not have such a situation, standing in front of the Guangzhou station clock, there is a feeling of bathing in the spring breeze of reform.
OPPO R9s really making proofs Click to enlarge
The HDR mode can only be turned on when it is fully backlit. It looks quite natural. Should be still Sony IMX398 + F1.7 aperture this pair of live treasure into the light enough, in the backlight position of the green leather car can be accurately exposed.
OPPO R9s really making proofs Click to enlarge
A handy shot on the roadside, the F1.7 aperture gave the OPPO R9s a very good out-of-focus blur effect. In addition, the tone processing of the image is also very pleasing, but the color is full but not exaggerated.
OPPO R9s really making proofs Click to enlarge
From another perspective, I feel that the colors of the photo taken by the OPPO R9s are seductive and have a sense of pleasure.
OPPO R9s really making proofs Click to enlarge
In the daylight OPPO R9s is a bit overwhelmed by the red reduction, and it feels a bit like Fuji. In fact, the red flowers are still very difficult to deal with, either as OPPO R9s overflows a little, the overall feeling of maintaining a bright light; or less exposed, but the picture faded.
OPPO R9s really making proofs Click to enlarge
Click here to see the original partner to see the picture will certainly find that OPPO R9s at 100% zoom details, there will be a certain pixelation of the blur. In simple terms, the edge of the subject is not clear enough. I hope it will be optimized in the next batch machine.
OPPO R9s really making proofs Click to enlarge
100% screenshot
In the low-light indoor environment, especially in the mall is the kind of warm dim light. If the color temperature is optimized to do a bad mobile phone, it is easy to appear yellow or cold. From the perspective of the proofs, OPPO R9s are still in place for color temperature control, and the restored scene is accurate.
OPPO R9s really making proofs Click to enlarge
OPPO R9s really making proofs Click to enlarge
OPPO R9s really making proofs Click to enlarge
Although the OPPO R9s built-in filter is not too much, but the effect is more classic. However, this one-by-one selection interface is still not used to it, and I feel it is more convenient to change it into a mainstream nine-square preview.
OPPO R9s filter system
Filters can make ordinary photos instantly get personalized style, so it is very suitable for travel, food shooting. However, using filters too often creates a dependency.
OPPO R9s Filter Samples Click to enlarge
OPPO R9s Filter Samples Click to enlarge
OPPO R9s Filter Samples Click to enlarge
OPPO R9s Filter Samples Click to enlarge
Since the OPPO R9s has such a good imaging foundation, plus a lot of adjustable details in the professional mode, the author who arrived in Shanghai before the press conference would have missed a good opportunity for this night shoot. I believe many of the Bund's past Partners will leave this picture. Unfortunately, today is cloudy, and the clouds are thicker, otherwise the translucent sky can produce more transparent images.
OPPO R9s professional mode, ISO: 100, backlight compensation: -3 files, exposure time: 2 seconds
OPPO R9s really making proofs
OPPO R9s really making proofs
This beauty self-defense
Like the R9, the OPPO R9s uses a 16-megapixel front camera with F2.0 aperture. However, self-timer mainly depends on the effect of beauty, but the hardware parameters are secondary. In addition to the usual leveling effect adjustments, OPPO R9s added a bokeh effect to the selfie. Well, it's the combined effect of a clear background blurring on the main body of a dual-lens mobile phone.
Open the selfie is not a beauty mode by default, is it right?
My sister was unwilling to go to the mirror because it is not in a good state of discomfort. Is it not good to test the effect of beauty? Everyone makes a point.
System: Mainly Secured ColorOS
Due to current phone fraud and SMS fraud, “security†has become a new job for smart phone manufacturers. According to OPPO's official data, OPPO R9s is not a secure business phone, but in the latest version of ColorOS 3.0, the "pseudo base station shielding " function has been added. This function will be turned on by default, it can automatically identify the characteristics of the pseudo base station signal and shield the information it sends.
ColorOS on OPPO R9s emphasizes safety
In addition to the automatic screening of pseudo-base station messages, OPPO R9s have stricter rules for calls and text messages. For example, in the figure below, “To intercept strange numbers for the first timeâ€, you can directly reject any unfamiliar calls after the activation. Of course, the user must diligently update the phone book, otherwise it will miss the phone. In fact, I think that the fraud prevention call can also be added to identify and remind the "change of the number " , "virtual operator number " and other security strategies.
ColorOS on OPPO R9s emphasizes safety
For fraudulent messages, messages sent from strange numbers will be screened, and text messages with URLs will be recognized online. Of course, this will consume a small amount of traffic, but it is worthwhile considering that security is more secure. PS: Any security policy is passive, tricks tricky, users still have to be careful about their own.
ColorOS on OPPO R9s emphasizes safety
The author tried a common fraud message, feel that the risk of the font can also be more eye-catching
In addition to preventing fraudulent calls and text messages, OPPO also has stricter specifications for software stores in R9s. It is reported that an APP that wants to be put on the OPPO App Store must undergo up to 48 steps of auditing, including manual inspections. Inappropriate apps, such as inducing deductions, pop-up ads, and illegally obtaining user information, will be removed.
The app in the store is clearly marked
For apps downloaded from non-system app stores, virus scanning will be performed before installation
Some risk behaviors require the user to manually confirm the password to prevent loss caused by hand mistakes.
It can be seen that the OPPO R9s has made many new attempts in terms of system security. As far as the basic operating interface is concerned, the OPPO R9s has no obvious changes, and the old OPPO users will not feel strange. Instead, I feel that ColorOS still insists on dividing the task management, shortcuts, and notification bar into three pieces, which is still slightly less efficient.
ColorOS 3.0 has abandoned the traditional pendant, calendar clock, weather are embedded in the APP icon
Of course, there are many new settings for improving the user experience in the OPPO R9s. For example, the lock screen magazine has appeared in the form of a group diagram. Users can read some new and interesting news directly on the lock screen interface. The more features of the OPPO R9s system are left for further exploration.
Lock Screen Magazine is a fun attempt at fragmented reading
Performance fever: the winter warm hands is no match
The OPPO R9s is equipped with a Qualcomm MSM8953 eight-core processor, the Xiaolong 625, running at 2.0GHz. This is Qualcomm's first 14nm eight-core processor and Qualcomm's first midrange processor with 14nm technology. It is reported that compared with the previous generation of Xiaolong 617, Xiaolong 625 power consumption to save 35%. Obviously, the intention of the OPPO R9s to use this processor is also obvious. It is to get better performance in terms of heat dissipation.
Snapdragon 625 eight-core processor
　　 OPPO R9s runs 65,000 in security rabbits, which is in line with the standard of Xiaolong 625 and 4GB memory combination. Compared to the OPPO R9 with Helio P10, the overall improvement is 25%. In the actual experience, R9s is much smoother than the R9 in program opening and multi-task switching.
OPPO R9s security Bunny Run points
In the days of OPPO R9s, PCMark Android has finally been updated. Unlike security rabbits, PCMark is more inclined to feedback actual experience. The tested items are divided into web browsing, video playing, writing, and photo editing, and imitating the actual use of the user to calculate the score.
Surprisingly, OPPO R9s' Snapdragon 625+4G memory combination (left) scores the same as Snapdragon 652+4G combo (right).
After reading the theory test, let's take a look at the performance of the game. First is the popular real-time strategy card game "Tribal Conflict: Royal Wars." Although the author is not a renminbi player, he is also considered to be an old driver of the 8th level. The little friends who have played this game know that because it is an online game, good networking and smooth operation are the basis for winning.
OPPO R9s Runs Tribal Conflict: The Royal War
From the recorded video, it can be seen that the process of OPPO R9s games has basically kept smooth, but when the other party sends troops, it feels like it will be stuck. I went to Baidu some time and found that players will reflect this situation, the use of mobile phones is not the same (Apple Andrews have), I guess this kind of Caton is more game or system optimization issues. Of course, I will still reflect this situation with the OPPO engineers.
Average frame rate reached 59FPS, this game eats more GPU
Then I installed the "King of Honor", this game is very popular, I also play a lot of beautiful young partners, I believe it is also very able to reflect the performance of a mobile phone game. Because here is more test fluency, so here I selected a medium quality in the settings.
OPPO R9s Run "The Glory of the King"
From the data recorded by GameBench, the average 25FPS score is quite satisfactory. Basic fluency can still be, if the online PK does not want to pit teammates, consider setting the picture quality.
The average frame rate is about 25FPS, which is in line with the performance of mainstream mobile games. The battery performance is also played for a long time (it can last 8.4 hours).
As mentioned earlier, the Snapdragon 625 is a mid-range processor with a low power consumption. After playing games and watching movies at a room temperature of 24 degrees Celsius, the OPPO R9s's hottest spot (upper right corner) is only 33 degrees Celsius. Left and right, because the back of the metal is also the same location but also two degrees lower. The warming process is still relatively long. The author probably measures the temperature after playing for one hour. Since it is autumn now, the author tried to test it in a heated room. However, from the current results, it is hopeless to plan to use the OPPO R9s for heating in the winter .
Room temperature 24°C, online game, post-video temperature test (front)
Room temperature 24°C, online game, post-video temperature test (back)
Reliable life performance
OPPO R9s has built-in 3010mAh battery, plus Xiaolong 625, which is known to consume less power. It can be seen that OPPO hopes that the R9s will have a more positive effect on the user's battery life. Under the condition that the brightness is set to 50% and WIFI is connected, the author tested the performance of OPPO R9s in movies, games and music. In 90 minutes, the total power consumption of the OPPO R9s was only 11%.
From the perspective of the similar power consumption of movies and games, the Snapdragon 625 is indeed a very power-efficient processor, and the major power consumer of the OPPO R9s is left with a 5.5-inch large screen. By adjusting the power saving mode and the appropriate screen brightness, it is believed that the OPPO R9s will have further improvements in battery life.
OPPO R9s battery life performance
OPPO R9s battery life performance
OPPO R9s battery life performance
Yes, this charging speed is very VOOC
Although the OPPO R9s are not charged for charging, VOOC flash charging is naturally standard. Like the OPPO R9, the new machine is equipped with a 5V/4A charging head. The key is that the OPPO R9s charge faster than the R9 when the battery capacity increases.
Bright screen fast charge is the advantage item of VOOC flash charge
The total charging time of the OPPO R9s with a built-in 3010mAh battery was only 73 minutes, with only 55 minutes from 0% to 95%. With emergency charging, you can charge from 0% to 64% in 30 minutes. It can be said that users of OPPO R9s do not need to worry about battery life, unless they don't bring a dedicated VOOC charger or there is no outlet.
The charging speed of OPPO R9s makes me very satisfied
Edit Comment
Although from the model point of view, OPPO R9s is just an iterative upgrade of R9. However, judging from the improvement of product experience, it is not too much for the new model to directly jump to the OPPO R10. Of course, continuing OPPO R9's high popularity is more conducive to product sales.
R9 post, OPPO R9s is still very reassuring
See here may be a small partner Tucao Xiaobian, whether it is the appearance of the camera, or battery life, OPPO R9s feel almost flagship performance. The author's answer is: Yes, ah, another dragon 821 or 820, OPPO R9s is a flagship machine.
As mentioned before, the micro slit antenna used by OPPO R9s is definitely a creative design. Without affecting the signal, the effect of a signal overflow antenna divided into three on the appearance of the fuselage is minimized. In fact, these tiny antenna feels are still a decoration or embellishment on the body.
The classic interpretation of simple design
As for photography, which is the biggest selling point of OPPO R9s, unlike other brands that jointly develop filters, the cooperation between OPPO and Sony has been based on the level of sensors. From the real shooting experience, the performance of the OPPO R9s camera is by no means empty talk. Do not say that the strength is rolling at the same level, and challenging the flagship is also very likely (turning back to a cross comparison test).
However, OPPO's positioning of the product is still very rational. Reviewing the mobile phone moving and system security strategies introduced at the conference, OPPO R9s is still based on the idea of ​​mass consumers. There is no need to contend for the first place, so you have to sit on the position of the emperor to make a good phone? It is better to honestly solve the needs of mainstream users for quality, appearance, photographing, and battery life.
Screen color is light
So there is no shortage of OPPO R9s? The answer is obviously there are, in addition to the author said the volume / power button has a virtual bit, this new machine's screen also want to spit it. The 5.5-inch screen of the OPPO R9s is bright enough, but the saturation and the leveling are a little less impressive. In addition, although the extroverts are quite traditional, they do not have enough exquisite sound.
About buying advice? First of all, the ashes player who pursues the ultimate performance can bypass; secondly, the small partner who is planning to pursue cost-effectiveness can also be closed; as for the rest of the small partners, it is hard for the author to find a reason not to recommend it to you.
